It’s been a while since I’ve played around with microcorruption, so I’m hoping that ramping back up shouldn’t take too long. Judging by the leaderboard, more people have actually finished this level than Jakarta, so that’s a good sign.
First pass
The last couple of levels tended to use long (or specific length) passwords to embed instructions into our input. Typing in a few test passwords has me thinking that that approach won’t work as well this time. The first new feature of this level that stands out is that our input is printed to the console “for verification”. Looks like they’re using printf for that, so maybe we can print out the password? We’re also running the test_password_valid check prior to printf, which makes me further suspect that some malicious formatting is the way forward.
Fun with Formatting
I spent some time looking at CMP calls and an ASCII code table before realizing that the behavior of printf is actually documented in the manual. We’ve got %s, %x, %c, and %n to play with (although I didn’t see any checks for %c in the code). The %n verb is the most interesting; it saves the number of characters printed so far.
Corruption
On my first few inputs, I stumbled upon a memory error. The input %s%x%n produces the error load address unaligned: 7825. Inspecting the memory dump just after the crash revealed %s%x in memory starting at 30ae. The crash happened due to this sequence of instructions:
cmp.b #0x6e, r14
jnz $+0x8 <printf+0xf6>
mov @r9, r15
mov r10, 0x0(r15)
So long as we’re currently reading an n character from our input, the program will load the value pointed to by r9 (30b0 in this case), then write whatever’s in r10 to the location pointed to by the loaded value. A little more investigation seems to show that r10 holds the number of characters preceding %n. This turns out to be important later.
Writing something useful
So far, all the values I’ve been able to write into 30b0 have included percent signs. There don’t appear to be any useful memory locations ending in 25, however. Can I write an arbitrary value to 30b0?
The instructions that control writing to that section of memory are a loop from 461a to 4626, which copies values from the input to a block ending at 30b2. The loop iterates over the input as many times as there are percent signs in the input, copying from just before the input (the first copied value is 0x000), so all that’s needed to write an arbitrary value to 30b0 is an input with the value followed by two formatting verbs. And if the second verb is %n, we’ll write the input length (2, in this example) to that location in memory.
Writing somewhere useful
I was considering the problem of how to enable writing to the program part of memory before I realized that I’d only be able to write values up to the input length limit. Considering that limitation, I started over looking at the main function and realized that the solution was simpler than I’d thought. The test_password_valid function writes a 1 or 0 to memory to indicate whether the password matches. And that memory location is already writeable.
Luckily, test_password_valid writes a 0 to indicate a password match, so unlocking the door only requires writing a non-zero value (the length of our non-verb input) to 30c6. With the memory address and two %n verbs, the door unlocks!
Finishing up
These are a lot of fun, so I’ll try to avoid going a year between puzzles again. The list of projects never seems to get any shorter though, so we’ll see.
